Protection
Safety lanyard (an essential protection feature standard on all Tohatsu outboards)
Specifications
Model / M3.5
Type
Two Stroke
Maximum output
HP (kw)
3.5 (2.6)
Maximum operating range
rpm
4200-5300
Fuel consumption at W.O.T
L/Hr (gal/Hr)
1.7 (0.45)
Number of cylinder
1
Bore x Stroke
mm (in)
47 x 43 (1.85 x 1.69)
Displacement
cc (Cu in)
74.6 (4.55)
Engine lubrication system
Premixed Fuel
Starting system
Manual
Spark plug
NGK BP6HS-10 or BPR6HS-10
Ignition timing
degree
BTDC20゜
Alternator output
-
Engine oil
Genuine recommended 2stroke engine oil (TCW-3)
Volume of engine oil tank
L (Gal)
-
Fuel tank capacity
L (Gal)
1.4 (0.37)
Speed control
Throttle lever type
Gear reduction ratio
Btype/Atype
2.15 (13:28) / 1.85(13:24)
Specifications and descriptions are subject to change without notice.
Standard & Optional Equipments
Type
S / L
Clutch
F-N (B-type) - (A-type)
Manual Starter
●
Engine Stop Switch Lanyard
●
Alternator
-
Oil Pre-Mixing
●
Transom
15 / 20
Propeller
●
Analog Tachometer
-
Analog Trim Meter
-
Rmote Control Box
-
12L Plastic Fuel Tank
-
1.4L In-tank
●
Tool Kit
●
Emergency Starter Rope
●
Spare Spark Plug
●
Owner's Manual
●
● Standard ○ Optional
